Household Glassware Machinery
SM-J91 auto glass sealing machine. PLC controlled with automatic loading manipulator. Seals round, flat, and conical bottoms. Diameter 35–120mm, length 180–600mm, output 1,100 pcs/h. Large-scale production capacity.
The SM-J91 Auto Glass Sealing Machine is a large-scale, fully automated glass container sealing machine for high-volume production. It handles a wide variety of glass containers — sealing round, flat, and conical bottoms — with a diameter range of 35–120mm and length range of 180–600mm. The machine features flexible PLC control and an automatic loading manipulator for continuous unattended operation at 1,100 pcs/h. Its large footprint (8.5 × 2.4m) and 4,000kg weight reflect its industrial production scale.
| Parameter | Value |
|---|---|
| Glass Diameter | 35–120mm |
| Glass Length | 180–600mm |
| Output | 1,100 pcs/h |
| Control | PLC + Automatic Loading Manipulator |
| Power | 8 kW |
| Gas Consumption | 3.2 kg/h |
| Oxygen Consumption | 28 L/h |
| Machine Dimensions | 8.5 × 2.4 × 1.86 m |
| Weight | 4,000 kg |
The SM-J91 combines three features that enable large-scale output: (1) an automatic loading manipulator that eliminates manual feeding, (2) a 1,100 pcs/h output rate, and (3) flexible PLC control that can run multiple product types without operator intervention between changeovers. At 4,000kg and 8.5m length, it is an industrial production-line machine rather than a workshop unit.
Standard lead time is 40 working days from order confirmation, as each machine is manufactured to order. For custom or modified machines, allow approximately 60 working days. Contact us for a specific timeline based on your requirements.
Yes — visit our Custom Orders page.
Electrical power as specified. Water and compressed air where indicated.
No — a full operation manual is supplied. Remote video training free.
7×24 remote support. Engineer assigned before shipment. See our After-Sales Support page.
This machine is designed and manufactured by Nantong Sea Melody Industrial Co., Ltd, a specialist glass machinery manufacturer based in Nantong, China, with over 24 years of experience. Sea Melody machines are currently operating in 35+ countries across pharmaceuticals, laboratory, and household glassware industries. All Sea Melody machines are produced under an ISO 9001:2015-certified quality management system. Learn more about Sea Melody →
